Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption

Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption

Energy Cascading Flexographic Printing Machine

800mm Flexographic Printing Machine

300m/min flexographic printing equipment

Place of Origin:

CHINA

Brand Name:

FENGMING

Certification:

CE

Model Number:

FM-VSP50

Contact Us
Request A Quote
Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption
Product Details
Type:
Data Processing Framework
Website:
Www.china-fmjx.com
Distributed Computing:
Yes
Supported Data Formats:
Hadoop, HDFS, Amazon S3, Local Files
License:
Apache License 2.0
Operating System:
Cross-platform
Scalability:
Yes
Developer:
Concurrent, Inc.
Parallel Processing:
Yes
Data Flow Optimization:
Yes
Fault Tolerance:
Yes
Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
wooden pallet
Delivery Time
30 working days
Payment Terms
T/T, L/C
Supply Ability
15 sets
RELATED PRODUCTS
Good price Auto Flexographic Printer, Front Side 9 Colors Back Side 1 Colors Flexo Label Flexographic Printer Printing Press online Video

Auto Flexographic Printer, Front Side 9 Colors Back Side 1 Colors Flexo Label Flexographic Printer Printing Press

Get Best Price
Good price Automatic Flexo Printing Machine Flexographic Printers Flexo Printing Machine Roll To Roll online Video

Automatic Flexo Printing Machine Flexographic Printers Flexo Printing Machine Roll To Roll

Get Best Price
Good price automatic Flexo Printing Machine Plastic Film and Paper label unit type flexo printing machine Colors online Video

automatic Flexo Printing Machine Plastic Film and Paper label unit type flexo printing machine Colors

Get Best Price
Good price FM-CS 1350 Flexo Printing Machine For Paper Plate With Online Video Technical Support online Video

FM-CS 1350 Flexo Printing Machine For Paper Plate With Online Video Technical Support

Get Best Price
Contact Us
86-577-63796999
Contact Now
Product Description

Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 0



Main Characteristics:



  • Vertical type printing, with centralized ink supply system, compact structure, small footprint.
  • The feeding route is short, the overprinting speed of the machine is fast, and the printing is stable.
  • Each printing group is independently driven by AC servo motor, stable work and high printing quality.
  • Unified drying after printing, the energy consumption of the whole machine is small.
  • The cylinder roller and anilox roller is clutched and driven by a servo motor with fast working speed and high positioning accuracy.

Applicable Object:

Paper, film, non-woven or other composite materials.



Application:

Paper tableware, paper (non-woven) bags, food packaging paper, food and medicine, packaging boxes.

Technical Parameter



Specification FM-VSP50
Max Material Width 1450mm
Max Printing Width 1430mm
Printing Repeat Length 300-870mm
Max. Unwinder Diameter 800mm
Max. Rewinder Diameter 800mm
Machine Speed 300m/min
Drying Mode Hot Air Drying/IR Drying
Ink Used Water based Ink
Total Power 70KW
Power Supply 380V 3PH 50Hz
Substrate 30-120gsm paper roll



Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 1Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 2Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 3Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 4Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 5Energy Cascading Flexographic Printing Machine With Small Footprint And Low Energy Consumption 6
